LCZ-202B Load Cell
Longlv LCZ-202B weighing sensor high-precision micro column tension and pressure sensor prestressed sensor
- Load rating：0~50KG
- Sensitivity：2.0±10%mV/V
- Zero point output：±2%F·S
- Material：Stainless steel
USD 107
output value: Monthly Output1000
- Product Description
Product Description
LCZ-202B column sensor has compact structure, high comprehensive accuracy, good long-term stability, high dynamic response frequency, and high-quality stainless steel material. It is widely used in automotive press-fitting, automated assembly, 3C product testing, new energy product assembly, medical testing, robotics, mold assembly and other industrial testing, automation equipment and testing fields.
Product Overview
 | LCZ-202B Column type tension and pressure sensor Column structure High precision and sensitive response Stable performance and good shock resistance |
Product Details
Detail pictures
Specifications
| Load rating | 0~50KG |
| Sensitivity | 2.0±10%mV/V |
| Zero point output | ±2%F·S |
| Nonlinear | 0.2%F.S |
| Hysteresis error | 0.1%F·S |
| Repeatability error | 0.1%F·S |
| Creep | 0.1%F·S |
| Zero point temperature coefficient | 0.1%F·S/10°C |
| Sensitivity, temperature coefficient | 0.1%F·S/10°C |
| Frequency of response | 10kHz |
| Material | Stainless steel |
| Impedance | 350Ω |
| Insulation resistance | ≥5000MΩ/100VDC |
| Voltage used | 5~10V |
| Operating temperature range | -20~80°C |
| Safety overload | 120%F·S |
| Extreme overload | 150% |
| Cable specifications | Ф2x2m |
| Cable limit pull | 10kg |
Product Dimensions
Fields of application
Supplier Information
Company：Shanghai Longlv Electronic Technology Co., Ltd.
Email：lonlvtech@ttbridge.com
Tel：0086
