Product Description

FR5-Robot Arm

This robot arm adopts a self-developed real-time control system, which integrates fully upgraded features such as flexibility, safety, flexibility, and ease operation, as well as excellent industrial-grade precision and stability.

High Precision Motion

* Repeatability up to ±0.02mm* Smooth multi-axis movement* Reliable industrial performance

Product parameters

Model	FR3	FR5
Payload	3kg(mAX 5KG)	5kg (up to 7kg)
Reach	622mm	922mm
Degrees of freedom	6	6
Pose repeatability per ISO	±0.02mm	±0.02mm
Axis movement	Scope of Work
Base	±175°	±175°
Shoulder	﹢85°/﹣265°	﹢85°/﹣265°
Elbow	±150°	±160°
Wrist 1	﹢85°/﹣265°	﹢85°/﹣265°
Wrist 2	±175°	±175°
Wrist 3	±175° (optional ±360°)	±175° (optional ±360°)
Typical TCP speed	1m/s	1m/s
IP classification	IP54 (optional IP65)	IP54 (optional IP65)
Noise	<65dB	<65dB
Tool I/O power supply	24V/1.5A	24V/1.5A
Footprint	128mm	148mm
Weight	≈15kg	≈22kg
Operating temperature	0-45℃	0-45℃
Operating humidity	90%RH(non-condensing)	90%RH(non-condensing)

Advantages

Excellent Performance

Efficiency First

Self-produced and self-researched core components, with patented design solutions, repeat positioning accuracy ±0.02mm, modular design to ensure stability.

Flexible Deployment

No Entry Threshold

Graphical programming, drag and drop robot programming, real-time and high stability, can be installed in any position of the production line, easy replacing, space saving.

Applications

Smart Assembly

Robotic arm assists in component assembly tasks.

Industrial Pick and Place

Automated picking and placement of parts in product.

Smart Assembly

Robotic arm assists in component assembly tasks.

Material Handling

Efficient handling of materials in warehouses and factories.

Product Size

FR3

FR5

Company Introduction

Avatar Intelligent Equipment Co.,Ltd. specializes in the R&D and supply of robotic prod-ucts and mobile solutions for robot platforms. Its core product line covers various robot application related products such as wall finishing robots, cleaning robots, grippers, and robotic arms. The company has built an integrated service system from R&D, quality inspection,production to sales and after sales service, providing customers with reliable intelligent equipment support through independent technical strength.
