YEJ series three-phase asynchronous brake motor has high braking torque and fast response

YEJ Series DC Brake Motors - Fast Response, Precise Positioning, Specialized for Machine Tools/Raising Equipment/Automation Equipment

NTEO OUTPUT：0.18~22（kw)
RATED SPEED：2800~2935(rpm)
EFF ICIENCY：65~90(η %)
POWER FOCTOR：0.8~0.9(COSφ)
RATED CURRENT：0.53~41.3（A）
RATED TORQUE：0.62~71.6（Nm）

USD inquiry

output value: Monthly Output200

contact shop

Product DescriptionProduct parameters

Product Description

YEJ series brake motor

Fast braking response speed and high reliability

The brake motor is composed of a three-phase asynchronous motor and a brake, and is a derivative series of three-phase asynchronous motors. The brake is divided into two forms: manual release and bolt release. The brake is the main component of the brake motor. Its working power supply is divided into two categories; One type is AC braking, and the other type is DC braking. At present, the brake motors produced by our company are all DC brake motors, which have the advantages of high braking torque, easy installation and debugging, fast braking response speed, high reliability, and strong universality.

YEJbrake motor code description

Product parameters

3000r/min 380V 50Hz

Type	NTEO OUTPUT	RATED SPEED	EFF ICIENCY	POWER FOCTOR	RATED CURRENT	RATED TORQUE	LOADED TORQUE	MAXIMUM TORQUE	STATIC BRAKE TORQUE NM	BRAKE TIME RATEDU RING IDLE
	NTEO OUTPUT	RATED SPEED	EFF ICIENCY	POWER FOCTOR	RATED CURRENT	RATED TORQUE	RATED TORQUE	RATED TORQUE	STATIC BRAKE TORQUE NM	BRAKE TIME RATEDU RING IDLE
	kW	rpm	η %	COSφ	A	Nm	T/s/Tn	Tmax/Tn	DC	s
YEJ－631－2	0.18	2800	65	0.8	0.53	0.61	2.2	2.2	3.5	0.1
YEJ－632－2	0.25	2800	68	0.81	0.69	0.85	2.2	2.2	3.5	0.1
YEJ－711－2	0.37	2830	70	0.81	0.99	1.25	2.2	2.2	4	0.1
YEJ－712－2	0.55	2830	73	0.82	1.4	1.86	2.2	2.3	4	0.1
YEJ－801－2	0.75	2840	75	0.83	1.83	2.52	2.2	2.3	7.5	0.1
YEJ－802－2	1.1	2840	77	0.84	2.55	3.7	2.2	2.3	7.5	0.1
YEJ－90S－2	1.5	2840	79	0.84	3.39	5.04	2.2	2.3	15	0.15
YEJ－90L－2	2.2	2840	81	0.85	4.8	7.4	2.2	2.3	15	0.15
YEJ－100L－2	3	2860	83	0.87	6.31	10	2.2	2.3	30	0.15
YEJ－112M－2	4	2880	85	0.88	8.22	13.3	2.2	2.3	40	0.15
YEJ－132S1－2	5.5	2910	86	0.88	11.2	18	2.2	2.3	80	0.15
YEJ－132S2－2	7.5	2910	87	0.88	15.1	24.6	2.2	2.3	80	0.15
YEJ－160M1－2	11	2930	88	0.89	21.3	35.9	2.2	2.3	150	0.3
YEJ－160M2－2	15	2930	89	0.89	28.8	48.9	2.2	2.3	150	0.3
YEJ－160L－2	18.5	2935	90	0.9	34.7	60.2	2.2	2.3	150	0.3
YEJ－180M－2	22	2935	90	0.9	41.3	71.6	2	2.3	200	0.3

1500r/min 380V 50Hz

Type	NTEO OUTPUT	RATED SPEED	EFF ICIENCY	POWER FOCTOR	RATED CURRENT	RATED TORQUE	LOADED TORQUE	MAXIMUM TORQUE	STATIC BRAKE TORQUE NM	BRAKE TIME RATEDU RING IDLE
	NTEO OUTPUT	RATED SPEED	EFF ICIENCY	POWER FOCTOR	RATED CURRENT	RATED TORQUE	RATED TORQUE	RATED TORQUE	STATIC BRAKE TORQUE NM	BRAKE TIME RATEDU RING IDLE
	kW	rpm	η %	COSφ	A	Nm	T/s/Tn	Tmax/Tn	DC	s
YEJ－631－4	0.12	1360	57	0.72	0.44	0.84	2.2	2	3.5	0.1
YEJ－632－4	0.18	1360	60	0.73	0.62	1.26	2.2	2	3.5	0.1
YEJ－711－4	0.25	1375	65	0.74	0.79	1.74	2.2	2	4	0.1
YEJ－712－4	0.37	1375	67	0.75	1.12	2.57	2.2	2	4	0.1
YEJ－801－4	0.55	1405	71	0.75	1.57	3.74	2.2	2.4	7.5	0.1
YEJ－802－4	0.75	1405	73	0.76	2.02	5.1	2.2	2.4	7.5	0.1
YEJ－905－4	1.1	1445	75	0.77	2.82	7.27	2.2	2.3	15	0.15
YEJ－90L－4	1.5	1445	78	0.79	3.7	9.91	2.2	2.3	15	0.15
YEJ－100L1－4	2.2	1440	80	0.81	5.16	14.6	2.2	2.3	30	0.15
YEJ－100L2－4	3	1440	82	0.82	6.78	19.9	2.2	2.3	30	0.15
YEJ－112M－4	4	1440	84	0.82	8.82	26.5	2.2	2.3	40	0.15
YEJ－132S1－4	5.5	1440	85	0.83	11.7	36.5	2.2	2.3	80	0.15
YEJ－132S2－4	7.5	1440	87	0.84	15.6	49.7	2.2	2.3	80	0.15
YEJ－160M1－4	11	1450	88	0.85	21.3	72.4	2.2	2.2	150	0.3
YEJ－160M2－4	15	1450	89	0.85	30.1	98.8	2.2	2.2	150	0.3
YEJ－180M－4	18.5	1455	90.5	0.86	36.5	121.4	2.2	2.2	150	0.3
YEJ－180L－4	22	1455	91	0.86	43.1	144.4	2	2.2	200	0.3

1000r/min 380V 50Hz

Type	NTEO OUTPUT	RATED SPEED	EFF ICIENCY	POWER FOCTOR	RATED CURRENT	RATED TORQUE	LOADED TORQUE	MAXIMUM TORQUE	STATIC BRAKE TORQUE NM	BRAKE TIME RATEDU RING IDLE
	NTEO OUTPUT	RATED SPEED	EFF ICIENCY	POWER FOCTOR	RATED CURRENT	RATED TORQUE	RATED TORQUE	RATED TORQUE	STATIC BRAKE TORQUE NM	BRAKE TIME RATEDU RING IDLE
	kW	rpm	η %	COSφ	A	Nm	T/s/Tn	Tmax/Tn	DC	s
YEJ-711-6	0.18	900	56	0.66	0.71	19.1	1.9	2	4	0.1
YEJ-712-6	0.25	900	59	0.68	0.95	2.65	1.9	2	4	0.1
YEJ-801-6	0.37	910	62	0.7	1.3	3.88	1.9	2	7.5	0.1
YEJ-802-6	0.55	910	65	0.72	1.79	5.77	1.9	2.1	7.5	0.1
YEJ-905-6	0.75	930	69	0.72	2.26	7.7	2.1	2.1	15	0.15
YEJ-90L-6	1.1	940	72	0.73	3.14	11.2	2.1	2.1	15	0.15
YEJ-100L-6	1.5	940	76	0.76	3.95	15.2	2.2	2.1	30	0.15
YEJ-112M-6	2.2	960	79	0.76	5.57	21.9	2.2	2.1	40	0.15
YEJ-132S-6	3	960	81	0.76	7.4	29.8	2.2	2.1	80	0.15
YEJ-132M1-6	4	960	82	0.76	9.63	39.8	2.2	2.1	80	0.15
YEJ-132M2-6	5.5	960	84	0.77	12.9	54.7	2.2	2.1	150	0.3
YEJ-160M-6	7.5	970	86	0.77	17	73.8	1.8	2.1	150	0.3
YEJ-160L-6	11	970	87.5	0.78	24.3	108.3	1.9	2.1	150	0.3
YEJ-180L-6	15	970	89	0.81	31.6	147.7	2.1	2.1	200	0.3

YEJseries installation size

IM B3 H63-180

Frame size	Installation Dimensions
Frame size	A	B	C	D	E	F	G	H	K	AB	AC	HD	L
63	100	80	40	ø11	23	4	12.5	63	ø7	135	120X120	170	270
71	112	90	45	ø14	30	5	16	71	ø7	137	130X130	185	315
80M	125	100	50	ø19	40	6	21.5	80	ø10	155	145X145	205	340
90S	140	100	56	ø24	50	8	27	90	ø10	175	160X160	225	400
90L	140	125	56	ø24	50	8	27	90	ø10	175	160X160	225	400
100L	160	140	63	ø28	60	8	31	100	ø12	200	185X185	245	440
112M	190	140	70	ø28	60	8	31	112	ø12	230	200X200	275	480
132S	216	140	89	ø38	80	10	41	132	ø12	270	245X245	330	567
132M	216	178	89	ø38	80	10	41	132	ø12	270	245X245	330	567
160M	254	210	108	ø42	110	12	45	160	ø14.5	320	335X335	450	780
160L	254	254	108	ø42	110	12	45	160	ø14.5	320	335X335	450	780
180M	279	241	121	ø48	110	14	51.5	180	ø14.5	355	370X370	500	880
180L	279	279	121	ø48	110	14	51.5	180	ø14.5	355	370X370	500	880

IM B14 H63-112

Frame size	Installation Dimensions
Frame size	D	E	F	G	M	N	P	S	T	AC	AD	L
63	φ11	23	4	12.5	75	60	90	M5	2.5	120×120	105	270
71	φ14	30	5	16	85	70	105	M6	2.5	130X130	112	315
80	φ19	40	6	21.5	100	80	120	M6	3	145×145	120	340
90S	φ24	50	8	27	115	95	140	M8	3	160×160	132	400
90L	φ24	50	8	27	115	95	140	M8	3	160×160	132	400
100L	φ28	60	8	31	130	110	160	M8	3.5	185X185	145	440
112M	φ28	60	8	31	130	110	160	M8	3.5	200X200	161	480

IM B34 H63-112

Frame size	Installation Dimensions
Frame size	A	B	C	D	E	F	G	H	K	M	N	P	S	T	AB	AC	HD	L
63	100	80	40	φ11	23	4	12.5	63	φ7	75	60	90	M5	2.5	135	120×120	170	270
71	112	90	45	φ14	30	5	16	71	φ7	85	70	105	M6	2.5	137	130X130	185	315
80	125	100	50	φ19	40	6	21.5	80	φ10	100	80	120	M6	3	155	145×145	205	340
90S	140	100	56	φ24	50	8	27	90	φ10	115	95	140	M8	3	175	160×160	225	400
90L	140	125	56	φ24	50	8	27	90	φ10	115	95	140	M8	3	175	160×160	225	400
100L	160	140	63	φ28	60	8	31	100	φ12	130	110	160	M8	3.5	200	185X185	245	440
112M	190	140	70	φ28	60	8	31	112	φ12	130	110	160	M8	3.5	230	200X200	275	480

IM B5 H63-180

Frame size	Installation Dimensions
Frame size	D	E	F	G	M	N	P	S	T	AC	AD	L
63	ø11	23	4	12.5	115	95	140	10	3	120×120	105	280
71	ø14	30	5	16	130	110	160	10	3	130×130	112	315
80M	ø19	40	6	21.5	165	130	200	12	3.5	145×145	120	340
90S	ø24	50	8	27	165	130	200	12	3.5	160×160	132	400
90L	ø24	50	8	27	165	130	200	12	3.5	160×160	132	400
100L	ø28	60	8	31	215	180	250	14.5	4	185×185	145	440
112M	ø28	60	8	31	215	180	250	14.5	4	200×200	161	480
132S	ø38	80	10	41	265	230	300	14.5	4	245×245	195	567
132M	ø38	80	10	41	265	230	300	14.5	4	245×245	195	567
160M	ø42	110	12	45	300	250	350	18.5	5	320×320	290	780
160L	ø42	110	12	45	300	250	350	18.5	5	320×320	290	780
180M	ø48	110	14	51.5	300	250	350	18.5	5	360×360	340	880
180L	ø48	110	14	51.5	300	250	350	18.5	5	360×360	340	880

IM B35 H63-180

Frame size	Installation Dimensions
Frame size	A	B	C	D	E	F	G	H	K	M	N	P	S	T	AB	AC	HD	L
63	100	80	40	ø11	23	4	12.5	63	ø7	115	95	140	10	2.5	115	120×120	170	280
71	112	90	45	ø14	30	5	16	71	ø7	130	110	160	10	3.5	136	130×130	185	315
80M	125	100	50	ø19	40	6	21.5	80	ø10	165	130	200	12	3.5	154	145×145	205	340
90S	140	100	56	ø24	50	8	27	90	ø10	165	130	200	12	3.5	180	160×160	225	400
90L	140	125	56	ø24	50	8	27	90	ø10	165	130	200	12	3.5	180	160×160	225	400
100L	160	140	63	ø28	60	8	31	100	ø12	215	180	250	14.5	4	205	185×185	245	440
112M	190	140	70	ø28	60	8	31	112	ø12	215	180	250	14.5	4	235	200×200	275	480
132S	216	140	89	ø38	80	10	41	132	ø12	265	230	300	14.5	4	261	245×245	330	567
132M	216	178	89	ø38	80	10	41	132	ø12	265	230	300	14.5	4	261	245×245	330	567
160M	254	210	108	ø42	110	12	45	160	ø14.5	300	250	350	18.5	5	320	335×335	450	780
160L	254	254	108	ø42	110	12	45	160	ø14.5	300	250	350	18.5	5	320	335×335	450	780
180M	279	241	121	ø48	110	14	51.5	180	ø14.5	300	250	350	18.5	5	355	370×370	500	880
180L	279	279	121	ø48	110	14	51.5	180	ø14.5	300	250	350	18.5	5	355	370×370	500	880

Product Display

Smooth surface treatment

Good surface treatment, polished before anti-corrosion treatment

Beautiful appearance and color, not easily corroded by organic solvents

High transmission efficiency

The reducer has high efficiency and low motor power

High output torque, low energy consumption, suitable for long-term use

Compact structure

Made of high-quality aluminum alloy die-casting, with precise structure and excellent performance

Characteristics such as low noise, long lifespan, and smooth operation

YEJwiring brake motor method

3kw motor (Y connection)

~380v

Rectifier

The black line

IThe brake coil

The black line

Above 4kW motors for(Aconnection)

~380v

Rectifier

The black line

IThe brake coil

The black line

STRUCTUREDIAGRAM

1	Oil seal	22	Brake disk	43	Rubber gasket seal
2	Front flange	23	Brake dust cover	44	Multiple terminal box
3	Spring washer	24	Hollow bolt	45	Rubber gasket seal
4	Inner hex screw	25	Brake stator	46	Cross recessed pan head screw
5	Enamelled copper wire	26	Spring washer	47	Rectifier
6	Stator core	27	Inner hex screw	48	Cross recessed pan head screw
7	Casting aluminum motor housing	28	Handle	49	Hexagon nut
8	Brake rear flange	29	Cable gland connector	50	Spring washer
9	Spring washer	30	Nameplate	51	Washer plain
10	Inner hex screw	31	Rivet	52	Washer plain
11	Fan blade	32	Side feet	53	Hexagon nut
12	Fan cover	33	Spring washer	54	Washer plain
13	Key	34	Inner hex screw	55	Cross recessed pan head screw
14	Motor shaft	35	Corrugate gasket	56	Terminal block
15	Key	36	Lead wire	57	Set screw
16	Bearing	37	Round bare terminal	58	Cross recessed pan head screw
17	Cast–aluminum rotor	38	Side feet	59	Spring washer
18	Bearing	39	Inner hex screw	60	Washer plain
19	Circlip for shaft	40	Spring washer	61	Washer plain
20	Splined Hub	41	Cross recessed pan head screw	62	Spring washer
21	Circlip for shaft	42	Multiple terminal box cover	63	Cross recessed pan head screw

核心细节展示

Pure copper wire

The coil adopts a brand new national standard copper wire

Ensure high efficiency and stability of the motor

safe operation

Deep Groove Ball Bearing

High precision and excellent noise reducing bearings,

Smooth and noiseless use, high quality,

Low loss, durable and long-lasting

High precision rotor

New national standard rotor, multiple precision machining, rigorous dynamic and static balance testing to ensure smooth and low-noise operation

Precision cold-rolled steel sheet

Cold rolled silicon silicon steel sheet has excellent ductility, compressive strength, and high-quality wear resistance
