Product Description

Product parameters

Model	Ratio Value	Allowable Moment (N.m)	Torsional Rigidity (N.m/(Arc.min))	Stat And Stop Allowing Output Torque (N.m)	Instantaneous Maximum Torque (N.m)	Transmission Accuracy (Arc.min)	Backlash Of Backlash (Arc.min)	Life (h)	Moment of inertia Input axis conversion value (kg・m²)	Weight (kg)
150BX	41/57/81.00	880	49	412	820	1.0	1.0	6000	6.07×10⁻⁴	4.70
	105.0								4.32×10⁻⁴
	121.0								3.56×10⁻⁴
	141.0								2.88×10⁻⁴
	161.0								2.39×10⁻⁴

Product Views

Wide Transmission Ratio Range

The speed ratio range of the single-stage cycloidal bevel gear reducer is from 1:6 to 1:119, with the efficient range being from 1:9 to 1:87. When using a two-stage transmission, the speed ratio can be extended to 1:7569 or even higher, enabling flexible matching of various working conditions' speed requirements.

Compact Structure

The cycloidal pinwheel reducer adopts a coaxial planetary transmission structure, which is compact in size. Compared with ordinary cylindrical gear reducers of the same specification, its volume and weight are reduced by 1/3 to 1/2. It is suitable for mobile machinery with limited space or those sensitive to weight.

Strong Overload Capacity and Impact Resistance

The smooth tooth profile design avoids stress concentration at the tooth root and ensures uniform distribution of contact stress, thus solving the problem of brittle teeth in involute gears. It has extremely strong shock and overload resistance, and can still operate reliably under short-term overload or intense shock conditions.

Long Service Life and Low Maintenance Costs

The core components are made of GCr15 bearing steel, which is quenched and finely ground to HRC 58-62. With rolling friction, the wear is extremely minimal. The small-sized models can be lubricated for life without maintenance. The design life is 2-3 times that of ordinary gear reducers.

Application Cases

CNC Machine

Material Handling and Logistics

Industrial Robot
